Tổ máy phát điện gió BERGEY EXCEL 10KW
Performance
• AWEA RATED POWER: 8.9 kW @ 24.6 mph (11 m/s)
• PEAK POWER: 12.6 kW
• AWEA ANNUAL ENERGY: 13,800 kWh @ 11 mph (5m/s) Average
• CUT-IN WIND SPEED: 5.6 mph (2.5 m/s)
• CUT-OUT WIND SPEED: None
• FURLING WIND SPEED: 31–45 mph (14–20 m/s)
• MAX DESIGN WIND SPEED: 134 mph (60 m/s)
• NOMINAL ROTOR SPEED: 0–400 rpm
Mechanical
• TYPE: 3-Blade Upwind, Horizontal Axis
• ROTOR DIAMETER: 23 ft. (7.0 m)
• WEIGHT: 1200 lb. (545 kg)
• GEARBOX: None
• OVER SPEED PROTECTION: Autofurl®
• TEMPERATURE RANGE: -40/140° F (-40/60° C)
• TOWERS: Guyed and Non-guyed 80–160 ft. (24–49 m)
• ALTERNATOR: 3Ø Neo Permanent Magnet
• INVERTER: 12 kW Powersync II
• Remote Monitoring Via Internet and Smartphones (Optional)
Tổ máy phát điện gió BERGEY EXCEL 10KW
The wise choice for Performance, Reliability, and Ruggedness
The Bergey Excel 10 is ideal for homes, farms, and small businesses. Its extra large rotor and low cut-in wind speed give it exceptional performance, out producing all other turbines in its class. More energy means greater savings and a quicker payback
Performance
• AWEA RATED POWER: 8.9 kW @ 24.6 mph (11 m/s)
• PEAK POWER: 12.6 kW
• AWEA ANNUAL ENERGY: 13,800 kWh @ 11 mph (5m/s) Average
• CUT-IN WIND SPEED: 5.6 mph (2.5 m/s)
• CUT-OUT WIND SPEED: None
• FURLING WIND SPEED: 31–45 mph (14–20 m/s)
• MAX DESIGN WIND SPEED: 134 mph (60 m/s)
• NOMINAL ROTOR SPEED: 0–400 rpm
Mechanical
• TYPE: 3-Blade Upwind, Horizontal Axis
• ROTOR DIAMETER: 23 ft. (7.0 m)
• WEIGHT: 1200 lb. (545 kg)
• GEARBOX: None
• OVER SPEED PROTECTION: Autofurl®
• TEMPERATURE RANGE: -40/140° F (-40/60° C)
• TOWERS: Guyed and Non-guyed 80–160 ft. (24–49 m)
• ALTERNATOR: 3Ø Neo Permanent Magnet
• INVERTER: 12 kW Powersync II
• Remote Monitoring Via Internet and Smartphones (Optional)
Advanced
• BW-7 Proprietary Low Noise Airfoil
• Powerflex Super High-Strength Blades
• Neo-10 Direct-Drive Permanent Magnet Alternator
• AutoFurl Storm Protection
• 12kW Powersync II Inverter
• Remote Monitoring (optional)
The Wise Choice
30 years ago, Bergey pioneered the radicallysimple “three moving parts design” that has proven to provide the best reliability, service life, and value of all of the hundreds of competitive designs that have come and gone in that time. A small wind turbine is a big investment and Bergey is clearly the wise choice.
