The DCH-5500EC is a high performance MPEG2 and H.264 HD encoder. It has a wide range of digital/ analog video and audio inputs: CVBS, HD-SDI, HDMI, YPbPr, SPDIF, AES/EBU and XLR balance Audio. Two pairs of stereo audios can be encoded using AAC, MPEG-1 layer II encoding or pass-through the audio data. The encoded video and audio transport stream is available from its TS_over_IP and ASI outputs. With this full range audio and video format compatibility, the DCH-5500EC addresses versatile MPEG2 and H.264 encoding market in the bandwidth scale from 250Kb/s to 25Mb/s.

Features:

• Supports MPEG-2 HD1/SD and H.264 HD/SD video encoding
• MPEG-1 Layer II, AAC LC and HE AAC audio encoding
• Supports 2 pairs of stereo audio encoding (Only for SDI and HDMI), CVBS and YPbPr only supports one pair stereo audio
• Multiple inputs include HDMI, HD-SDI, YPbPr ,CVBS, SPDIF, AES/EBU and XLR balance Audio
• Video encoding bit rate from 250Kb/s to 25Mb/s
• Vertical & Horizontal video resolutions rescaling
• Multiple video resolution including 1080i, 720p, 576i and 480i
• Support VBR and CBR encoding mode
• ASI and TS/IP outputs
• Supports 10/100M TS/IP SPTS
• Optimized video pre-processing algorithm
• Remote Control and Supervision with HTTP WEB

Specifications:

Video Compression
Video Resolution    1080i (1920/1440×1080) @25Hz,
29.97Hz, 30Hz: SMPTE 292M
720p (1280×720) @50Hz, 59.94Hz,
60Hz: SMPTE 292M
480i (720×480) @29.97Hz: SMPTE 259M
576i (720×576) @25Hz: SMPTE 259M
Compression Standard    H.264: MP@L4.1, HP@L4.1 (HD);
MP@L3.0, HP@L3.0 (SD)
MPEG-2: MP@HL (HD);
MP@ML (SD)
Aspect Ratio    4:3/16:9 selectable
Video Encoding Bit Rate    250Kb/s-20Mb/s

Audio Compression
Audio Compression    MPEG-1 Layer II, AAC LC, HE AAC
Audio Input    SDI or HDMI Embedded Audio, Analog
audio, and SPDIF
Audio Sampling Rate    32Kb/s, 44.1 Kb/s, 48 Kb/s
Audio Compression Bit Rate    192-384 Kb/s (MPEG-1 Layer II), 32-192Kb/s
(AAC)
MUSICAM    Stereo, Dual Mono, Left Mono, Right Mono

Audio/Video Input Interface
Analog Audio    RCA (L/R)
Digital Audio    1×S/PDIF
Analog Video    YPbPr
Digital Video    HD-SDI, 1×BNC Female, 75Ω
HDMI 1×HDMI 1.3
TS over IP
Connector Type    1×RJ-45, 10/100M for TS/IP
Useful Bit Rate    70Mb/s for 10/100M
Protocol    UDP / RTP, Multicast / Unicast,
Source    Encoder

ASI Output
Connector Type    1×BNC Female, 75Ω
Output Bit Rate    ≤ 99Mb/s
Packet Length    188 / 204 Bytes
Signal Level    800mVpp±10%
Source    Encoder

Control & Monitoring
Connector Type    1×RJ-45, 10/100 Base-T, for equipment
control
Remote Control    HTTP Web interface
Local Control    LCD display and 6-key keypad
Software Upgrade    Built-in FTP loader and Telnet

Physical
Dimensions    483mm×498mm×44mm
Net weight    5Kg
Power supply    AC90~250V 50Hz/60Hz
Power Consumption     15W
Operating Temperature     0~45℃
Storage Temperature     -10~60℃
Humidity    10~90%, non-condensed
Certification
EMC: EN 55024:1998+A1:2001+A2:2003, EN 55022:2006+A1:2007,
EN 61000-3-2:2006, EN 61000-3-3:2008
FCC: Part 15 Class B
LVD: EN 60950-1:2006 + A11:2009
