ECS4510-28T Edgecore SMC Switch / L2+ Gigabit Ethernet Stackable Switch
ECS4510-28T Edgecore SMC Switch / L2+ Gigabit Ethernet Stackable Switch
Thông tin chính sản phẩm:
+ 24 x 10/100/1000 Base-T ports, 2 x 10 Gigabit SFP+ port and 1 x expansion slot.
+ OAM
+ Fanless Design
+ Hardware Stacking
Tham số kỹ thuật chính:
| Physical Configuration | |
| Dimension (HxWxD) cm | 4.4 x 44 x 31.5 |
| Expansion Slots | 1 |
| Fixed Ports | 24 |
| Out-of-Band Management | Console Port |
| Packet Buffer | 1.5MB |
| SDRAM for CPU | 256MB |
| Weight (kg) | 3.7KG |
| Performance | |
| Forwarding Rate | 95.23Mpps |
| MAC Address Table Size | 16K |
| Switching Capacity | 128Gbps |
| L2 Features | |
| Auto MDI/MDIX | Yes |
| Flow Control | Yes |
| IGMP Snooping | v1 | v2 |
| Jumbo Frame | Yes |
| Link Aggregation | IEEE 802.3ad with LACP (Dynamic) | Cisco EtherChannel Liked | Unicast / Multicast traffic Balance over Trunking port |
| Multicast (IGMP) Snooping | Querier Support | Immediate Leave | IGMP Filtering | IGMP Throtting | IGMP Leave Proxy | MVR Support |
| MVR | Yes |
| Q in Q | Yes |
| Spanning Tree | IEEE 802.1D (STP) | IEEE 802.1w (RSTP) | IEEE 802.1s (MSTP) | Spanning Tree Fast Forward | BPDU Filter | BPDU Forward | Root Guard | BPDU Guard | Loopback Detection | Auto Edge Port |
| Storm Control | Broadcast | Multicast |
| Unicast / Multicast traffic Balance over Trunking port | Yes |
| VLAN | IEEE 802.1Q Tagged Based | Private VLAN | GVRP | IEEE 802.1v | MAC Based | IP Subnet VLAN | Port Based | Voice VLAN | VLAN Trunking |
| VLAN Group | 4K |
| QoS Features | |
| CoS | IEEE 802.1p | DSCP |
| DiffServ (RFC2474) | Yes |
| H/W Queues | 8 |
| Priority Queue Scheduling | WRR | Strict Priority | Hybrid |
| Rate Limiting | Ingress | Egress |
| Security Features | |
| ACL | Time-Based |
| ACL L2/L3/L4 | Yes |
| Dynamic ARP inspection (DAI) | Yes |
| HTTP and SSL ( Secured Web) | Yes |
| IEEE 802.1x | Port-based | MAC-based | VLAN Assignment | Guest VLAN |
|
| |
