AIRMATE-USB 8 channel (with 6 triple  and 2 dual inputs)

radio production console

Features:

6x Mic inputs, 12x stereo line inputs

4x inserts on Mic input 1-4

2x USB stereo send/return

2x Built Telephone Hybrids

FADER STARTS AND CLEAN FEEDS ARE STANDARD

We designed the Airmate-USB to fulfill the requirements for a high grade low cost radio production mixer.

Built around well proven low noise circuitry, this console is the reliable workhorse for the self-op production D.J. that needs an internal Telephone Hybrid (2x) and

USB connection to the PC (e.q. for streaming to the web).

A heavy duty 19" rack mounted RF shielded chassis houses 8 vertical triple input modules giving flexibility rarely found in a mixer of this type.

Six input channels with high quality balanced microphone inputs on XLR and two stereo line level inputs on Cinch (RCA) connectors.

Every Mic input has an insert for signal processors.

And… every line level line B input can be converted into a phono (gramophone) channel by simply fitting an optional stereo R.I.A.A. equalized phono pre-amp.

BUILT IN TELEPHONE HYBRIDS

This new Airmate-USB model has 6 balanced mic inputs (+48 phantom is standard) with insert, 12 stereo line inputs, 2x USB and 2x Telephone Hybrids.

Channel 5 and 6 have Mic/Line and USB interface to transfer audio from and to your PC.

Channel 7 and 8 have, apart from the stereo line input, also RJ-11 connectors to interface with a POT (Plain Old Telephone) line and a Telephone appliance to dial the number you want to reach.

High quality built in Hybrids with R (trimmer on the surface) and C balance (switch on the surface) and direct Connection and Talkback buttons in the Hybrid channels makes a conversation with listeners very easy.

With the Telco Send (level to the caller) and Telco Gain (level coming from the caller) all levels can be easy adjusted.

VOIP

If you would like to call with VOIP we would advice to use the CISCO SPA112 as an interface in between the Airmate-USB Hybrid circuits and the PC.

NOW IS THE TIME TO INSTALL YOUR OWN PRODUCTION ROOM

The Airmate-USB has the usual master controls such as stereo master faders, stereo Aux send and return, monitor master with "follow phones" and a phones output with a split control function. There is a balance control to continuously adjust the volume between main output and stereo Cue signal.

In addition, there is a special Radio On-air/production section featuring; Self­op switching to automatically cut control room level when the D.J. mic is active; a Clean feed output to also drive an external Telephone Hybrid for talk shows and interviews, if you need more Hybrid channels than the 2 built in ones; a special announcer output that normally follows main output but can be switched so that the main output, or any cue signal that is selected, can be heard when in the "follow phones" mode.

A large Talkback switch activates the built-in electret talkback microphone for easy communication with the Clean-feed output, Aux output and/or Announcer output.

THE FOCAL POINT IN A PRODUCTION STUDIO

The Airmate-USB is designed to be the focal point for local radio production work in the studio or at home. It’s compre­hensive, yet understandable features make it the ideal companion for rapid on-the-spot radio programs.

Small, reliable and 19" rack mounting ideal for production rooms.

It can also double as an On-Air mixer or implemented in your own Internet Radio station.

If your budget is tight, it never becomes obsolete as it can revert to production use, if, at a later date you fit in a larger On-Air mixer.
