Aberdeen AberNAS N33W N33L - 3U/16 Bays Windows/Linux NAS storage server
Aberdeen AberNAS N33W N33L - 3U/16 Bays Windows/Linux NAS storage server
|
Aberdeen AberNAS N33W N33L - 3U/16 Bays Windows/Linux NAS storage server |
|
|
Product Type |
3U Rackmount SAS RAI D Controller |
|
Color |
Black |
|
Watts |
1000W |
|
External Drive Bays |
16 x 3.5" hot-swap SAS/SATA drive bay with SES2 Optional 2 x 2.5" hot-swap drive bay |
|
Cooling Fans |
3 x 8cm hot-swap redundant PWM cooling fans |
|
Dimensions (WxHxD) |
17.2" (437mm) x 5.2" (132mm) x 25.5" (647mm) |
|
Data Transfer Rate |
12Gb/s SAS |
|
Internal Ports |
8 Ports |
|
External Ports |
8 Ports |
|
I/O Processor |
LSI SAS3516 |
|
Cache Memory |
4 GB 2133MHz DDR4 SDRAM |
|
RAID Levels |
0, 1, 5, 6, 10, 50, 60 |
|
Max Devices |
SAS/SATA: 240 |
|
Storage Capacity |
2 x 240GB |
|
Interface |
6.0Gb/s Serial ATA |
|
North Bridge |
Intel C624 |
|
Memory Technology |
DDR4 ECC Registered |
|
Memory Slots |
16x 288-pin DIMM sockets |
|
Expansion Slots |
3x PCI-E 3.0 x16 |
|
Graphics Controller |
Aspeed AST2500 BMC |
|
Network Controller(s) |
Dual 10GBase-T LAN ports via Intel® X557 |
|
On-Board Interfaces |
SATA3 (6Gbps); RAID 0, 1, 5, 10 |
|
USB 3.0 Ports |
7x USB 3.0 (4 rear + 2 front header+ 1 type A) |
|
VGA Ports |
1x VGA port |
|
Read IOPS |
92,000 IOPS |
|
Write IOPS |
28,000 IOPS |
|
Read Speed |
560 MB/s |
|
Write Speed |
320 MB/s |
|
NAND |
3D NAND TLC |
|
Processor |
|
|
Product Line |
Xeon Scalable |
|
Socket |
LGA3647 |
|
Clock Speed |
2.60 GHz |
|
Cores/Threads |
4C / 8T |
|
Intel Virtualization Technology |
Yes |
|
Intel Hyper-Threading |
Yes |
|
Wattage
(Aber NAS) |
85W |
