OVERVIEWS:
• 18.5” LED 3G-SDI Monitor
• 1366 x 768 Resolution
• IPS LED Backlight Panel
• RJ-45 Remote Control
• HDMI to SDI Convert & Display Out
PRODUCTS FEATURES:
| Model Number: VZ-185PM-3G |
| Multi-Format Support |
| High Resolution (1366 x 768) |
| Embedded HDMI-SDI & SDI-HDMI converter |
| HDMI to SDI Convert & Display Out |
| IPS LED Backlight Display with 12bit Processing |
| 2K Input Capability |
| Wide Color Gamut |
| Precise White Balance & Gamma |
| Real-time Waveform & Vectorscope Display |
| Zoom Mode |
| Jog Dial for Easy Menu Selection |
| UMD Support |
| Programmable Function Key |
| H/V Delay |
| Freeze Display |
| Aspect Setting |
| De-Imbedded Audio Level Meter (16ch) |
| Pixel to Pixel View |
| Red/Green Mode Tally |
| Time Code |
| Various Markers |
| On-Screen Menu |
| Screen Color Mode: Blue, Red, Green & Mono |
| Maximum Brightness (On/Off) |
| Key Lock |
| Built-in Speaker |
| RJ-45 Remote Control |
| Front and Rear Phone Jack |
DISPLAY:
Screen Size | 18.5 inch (IPS) |
Max Resolution | 1366 x 768 |
Brightness | 250cd/m² |
Contrast Ratio | 1000:1 |
Aspect Ratio | 16 : 9 |
Viewing Angle (H/V) | 178°/178° |
Color Depth | 16.7M (8 Bit) |
IN/OUT
SDI In / Out | 1 / 1 (2/1 option) |
HDMI In / Out [DVI-D support] | 1 / 1 |
Component In (BNC jack) | 3 |
AV (Composite) In / Out (BNC Jack) | 3 / 1 |
RS-485 In / Out | 1 / 1 |
PC Audio In / Out | 1 / 1 |
Audio In L/R (Analog Stereo) | 1 / 1 |
VGA (15 pin RGB) [DVI-I support] | |
