Aberdeen S41/S42 S-Series JBOD Expansion

Đối tác của chúng tôi

Aberdeen S41/S42 S-Series JBOD Expansion - 4U 45Bay SAS/SATA 6G

Trạng thái: Còn hàng

Liên hệ

Ports	Four or Two 6Gb/s SAS ports
Drive Support	45x (24 front + 21 rear) 3.5" Hot-swap HDD bays SAS or enterprise SATA HDD only recommended
Form Factor	4U Rackmount
System LED	Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED Power Fail LED
High-Availability Features	Redundant Power Supplies Redundant Hot Pluggable Cooling System Hot-Swap Drives
Power Supply	1400W high-efficiency (1+1) redundant power supply with PMBus AC voltage: - 1100W: 100 - 140V, 50 - 60Hz, 9.5 - 13.5 Amp - 1400W: 180 - 240V, 50 - 60Hz, 7.0 - 9.5 Amp Certification 80 PLUS Gold Certified
Environmental	Temperature: 10 to 35°C operating/ -40 to 70°C non-operating Altitude: Sea level to 3660m (12,000ft) operating / sea level to 12,192m (40,000ft) non-operating Relative humidity: 8 to 90% non-condensing, operating
Dimensions	Without chassis ears / protrusions: 437mm (W) x 178mm (H) x 699mm (D)
Weight	Without HDDs:36.3kg (80lbs)

Số lượng:

4U 45-Bay SAS 6G Storage JBOD

The new Aberdeen JBOD S-Series S41/S42 are 6Gb/s SAS-based expansion enclosures that can accommodate forty-five (45) SAS/SATA drives in a 4U form factor and features a redundant 1400W Gold Level power supply. The expansion enclosure allows users to easily attach terabytes of capacity to any Aberdeen server with either Areca-1880/1882 SAS or LSI SAS external minisas raid port. Hot-Swap drive bays are used for the front and back of the chassis. Twenty-four (24) front and twenty-one (21) rear hdd bays are provided. Single and dual expander models are available for standard or high availablility scenario

FEATURES
