PROWARE 16 Bays NAS - EPICa Series EN-3163 6G SAS NAS
Hardware Platform
Intel Quad Core Xeon 2.0G or above, single / dual Processor
Cache memory: 3GB DDR3 SDRAM up to 32GB
Two Gigabit Ethernet ports (10 Gigabit Ethernet for additional option)
Up to Sixteen 1" hot-swappable 6G SAS/SATA3 (6Gb/s, NCQ support) hard drives
Real time drive activity and status indicators
Two(2) 460W 80plus hot-swap power supplies with PFC
Option:Two(2) 550W 80plus hot-swap power supplies with PFC for dual processor
Expansion PCI slot for H/W upgrade
One(1) 4X SAS Host port for RAID Host connection
One(1) 4X SAS Expansion port for JBOD connection (up to 7 SAS JBOD enclosures, max. 128 disks)
One(1) 4X SAS HBA port for next DAS connection (max. 128 disks with 1 RAID + 7 JBOD enclosures)
RAID Controller Specifications
800MHz RAID-On-Chip storage processor
Supports RAID level: RAID 0, 1, 10(1E), 3, 5, 6, 30, 50, 60 and JBOD
Onboard 1GB ECC/Registered cache memory
Supports hot spare and automatic hot rebuild
Support MAID (spin down drives when not in use to extend service)
Allows online capacity expansion within the enclosure
Local audible event notification alarm
Storage Management
Volume Management (Support XFS, ext3 & ext4 file system)
- Support two Gigabit Ethernet port for NAS file-sharing application
- Support one SAS port for direct access of RAID host connection
- Support Fiber target for Fiber storage environment (Optional)
- Support iSCSI target for IP storage environment
- Smart-function LCD panel for RAID & ENC status display and IP address setting
- Supports hot spare and automatic hot rebuild.
- Allows online capacity expansion within the enclosure
- Support spin down drives for power saving (MAID) and disk drive power cycle
- Schedule volume check data correctness by RAID 3/5/6
- 64 bit Linux-based embedded system
- Supports Tape/DAT backup/restore (Option)
- Centralization of Data and Storage Management
EN-3163S6H-NQX NAS/DAS(SAS/Fiber)/iSCSI All in One RAID Subsystems
NAS Features
- Configurable to 19" rack-mountable 3U chassis
- INTEL Nehalem based
- Supports up to Sixteen (16) 1" hot - swappable 6G SAS/SATA3 hard drives
- Supports RAID levels 0, 1, 10(1E), 3, 5, 6, 30, 50, 60 and JBOD
- Support NAS, DAS(SAS/Fiber) and iSCSI in one system
- Support two Gigabit Ethernet port for NAS file-sharing applicgation
- Support one SAS port for direct access of RAID host connection
- Support Fiber target for Fiber storage environment (Optional)
- Support iSCSI target for IP storage environment
- Smart-function LCD panel for RAID & ENC status display and IP address setting
- Supports hot spare and automatic hot rebuild.
- Allows online capacity expansion within the enclosure
- Support spin down drives for power saving (MAID) and disk drive power cycle
- Schedule volume check data correctness by RAID 3/5/6
- 64 bit Linux-based embedded system
- Supports Tape/DAT backup/restore (Option)
- Centralization of Data and Storage Management
- Using Market-Leading Java Technology
- Latest volume snapshot technology
- Apply volume replication to enhance data protection
- Data Backup via backup plan and scheduling
- Enhance system configuration backup
- Local and external account management, support large account import
- Share management and permission (support ACL setting)
- Support Internet Gateway function
- Online expansion file system
- Support E-mail notification and system log information
- Multi application support via proFamily
