System highlites
- 6 to 126 Alps faders
- Faders can be used for channel faders and buss master faders
- Scalable On-Air/Production Console
- Separated control surfaces and I/O racks
- Control surfaces connected by Ethernet.
- Internal website for console setup. (already pre-programmed in the factory)
- I/O matrix of 1280 x 1280
- 16 stereo summing buses (Prog, Sub, Cue, Comm, 12x Aux) and 4 stereo monitoring buses
- 16 Talk back buses
- 4 stereo monitor buses per DSP card
- Inputs can directly assigned to the outputs
- 128 Stereo DSP channels max (4 DSP Cards inserted)
- Digital gain control
- 6 band comprehensive EQ
- Enhanced Voice Processing built in
- Processing presets
- Module presets
- Console presets
- Direct outputs available
- Converters are 24bit / 96kHz
- Cobra Net option
- Assignable channel meters in version 3.0
- Pop up Equalizer graphics per channel
- On-Air indication on screen
- Phone indication on screen
- Phase meters on modules, buses, monitor
- High precision Broadcast Clock
- Redundant power supply optional for both Control Surface and I/O rack
- Optional Remote Control Surface application
