Aberdeen S-Series JBOD Expansion - 2U 24Bay SAS/SATA 6G

Đối tác của chúng tôi

Trạng thái: Còn hàng

Liên hệ

Host Ports	Four or Two 6Gb/s SAS ports
Drive Support	24x 2.5" Hot-swap HDD bays SAS or enterprise SATA HDD only recommended
Form Factor	2U Rackmount
System LED	Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED Power Fail LED
High-Availability Features	Redundant Power Supplies Redundant Hot Pluggable Cooling System Hot-Swap Drives
Power Supply	1280W Redundant High-efficiency Digital Power Supplies w/ PMBus 1.2 - AC: 1000W Output @ 100-140V, 12-8A, 50-60Hz DC: +12V/83A; +5Vsb/4A - AC: 1280W Output @ 180-240V, 8-6A, 50-60Hz DC: +12V/106.7A, +5Vsb/4A Certification 80 PLUS Platinum Certified
Environmental	Temperature: 5 to 35°C operating/ -40 to 60°C non-operating Altitude: Sea level to 3660m (12,000ft) operating / sea level to 12,192m (40,000ft) non-operating Relative humidity: 8 to 90% non-condensing, operating Relative humidity: 5 to 95% non-condensing, non-operating
Dimensions	Without chassis ears / protrusions: 437mm (W) x 89mm (H) x 630mm (D)
Weight	Without HDDs:25.9kg (57lbs)

Số lượng:

2U 24-Bay SFF SAS 6G Storage JBOD

The new Aberdeen JBOD S-Series S21m/S22m are 6Gb/s SAS-based expansion enclosures that can accommodate twenty-four (24) SAS/SATA 2.5" SFF drives in a 2U form factor and features a redundant 1280W Platinum Level power supply. The expansion enclosure allows users to easily attach terabytes of capacity to any Aberdeen server with LSI SAS external minisas raid port. Hot-Swap drive bays are used in the front of the chassis. Sixteen (16) front 2.5-inch hdd bays are provided. Single and dual expander models are available for standard or high availablility scenarios.

FEATURES
