AberNAS N32W Series - 3U/16HDD WSS2012 R2 NAS

Trạng thái:  Còn hàng



MODEL

N32W

FORM FACTOR

3U, 19" Rackmount (25.5" in Depth)

BASE CAPACITY

128 / 96 / 64 / 32 Terabytes

PROTOCOL SUPPORT

CIFS, NFS, NCP, HTTP and FTP

OPERATING SYSTEM

Windows® Storage Server 2012 R2 (64-bit)

CONFIGURABLE
PROCESSOR

Dual Socket R3 (LGA 2011) supports Intel® Xeon® E5-2600 v3
(Haswell-EP/Broadwell-EP)
Ten/Eight/Six Cores w/up to 9.6GT/s QuickPath Interconnect
- 9.6GT/s QPI CPU runs DDR4 at 2133/1866/1600MHz
- 8.0GT/s QPI CPU runs DDR4 at 1866/1600MHz
- 6.4GT/s QPI CPU runs DDR3 at 1600MHz

CONFIGURABLE
MEMORY

32GB to 1TB ECC DDR4 (Quad Channel Operation)
(64-bit OS allows for maximum memory support)

AVAILABLE
EXPANSION SLOTS

6 x PCI-E 3.0 x8

RAID ENVIRONMENT

LSISAS3108 dual core RAID on Chip (ROC)
1 x PCIE 3.0 SAS 12G RAID Controller
1 x RAID CacheVault SuperCap
Rear SFF-8644 HD MiniSAS Expansion Port

HOT SWAP

16 Bays

OS DRIVE
(MIRRORED SET)

2 x 120GB SSD
Rear Hot-Swap

CHOICE OF DATA
DISK DRIVES

16 x SAS 12G / SATA 6G
8TB / 6TB / 4TB / 2TB
24x7 Enterprise-Class

ETHERNET

Intel® X540 Dual port 10GBase-T
Virtual Machine Device Queues reduce I/O overhead
Supports 10GBase-T, 100BASE-TX, and 1000BASE-T, RJ45 output

ETHERNET LOAD BALANCING

Load Balancing, Teaming and Failover

POWER SUPPLY

920W Redundant High-efficiency
80PLUS Platinum Level (94%+)

RAILS

Tool-less rails included

WARRANTY

5 year Limited

POWER DRAW(W)

Off: 16.8
Boot-Up: 558
Burn-In: 574
Idle: 367

DIMENSIONS

Height: 5.2" (132mm)
Width: 17.2" (437mm)
Depth: 25.5" (648mm)





Số lượng:

FEATURES


Windows NAS

Aberdeen AberNAS N-Series for Windows have been designed for use with the latest Microsoft Windows Storage Server 2012 R2. Windows Storage Server 2012 R2 offers a number of greatly enhanced capabilities and benefits when compared with previous versions. Windows Storage Server 2012 R2 delivers excellent economics for a shared storage solution by gaining leverage from industry-standard hardware matched with robust storage capabilities. It delivers continuous availability that is designed to protect organizations from a range of failures and to help prevent downtime, and it offers organizations a scalable and reliable solution. Other new features include next generation processors, improved expansion bus tecnology, greater memory capacity and more efficient power supplies.



Featuring Intel® Xeon® Processor E5 v3 Family

The latest members of the Intel Xeon processor E5 family deliver the best combination of performance, built-in capabilities, and cost-effectiveness to address technical computing challenges, enable cloud deployments, accelerate processor performance for peak loads, deliver intelligent storage or power data analytics. In comparison to previous generation processors you get:

    • Up to 3x more performance
        • The world's most energy efficient server
            • Up to 1.9x more performance with Intel® AVX 25
                • Up to 1.7x increased virtual machine density
                    • Up to 1.4x increased memory bandwidth with DDR4

                      Opening the server storage bottleneck

                      12Gb/s Serial Attached SCSI (SAS) technology enables a new performance, class of storage tiering that spans servers with solid state drives to hyperscale datacenter scale-out architectures. The interface doubles the data transfer rate of 6Gb/s SAS solutions, allowing SAS infrastructures to deliver bandwidth that exceeds that of PCI Express® 3.0 with a single host bus adapter (HBA).

                      12Gb/s SAS enterprise-proven solutions provide the connectivity, scalability, performance and manageability required for the most demanding enterprise storage applications.



                      Intelligent Platform Management Interface

                      For hardware-level platform monitoring and control functions, the IPMI protocol utilizes an out-of-band network to provide a flawless and secure path for mission-critical applications when regular in-band connectivity is lost or is unresponsive. Remote access for monitoring and administration allows the server administrators to view a server's hardware status remotely, receive an alarm automatically if a failure occurs, and power cycle a system that is non-responsive.



                      AberNAS W-Series Highlights:

                        • VMware NAS and iSCSI storage certified
                            • Microsoft Windows Storage Server 2012 R2
                                • IPMI w/KVM over LAN for Remote Server Management
                                    • SAS 12G Storage Support
                                        • Intel E5-2600 v3 Series Support
                                            • 1TB DDR4 Memory Support
                                                • PCI-E 3.0 Support
                                                    • Intel® X540 Dual port 10GBase-T
                                                        • RAID 0, 1, 5, 6, 10, 50, 60 Configurable
                                                            • High efficiency redundant power supply
                                                                • Hardware RAID w/ SuperCap
                                                                    • iSCSI Target Capable
                                                                        • JBOD expansion without the need for an additional RAID controller
                                                                            • Supports Direct Attached Storage Expansion with XDAS
                                                                                • Embedded Flash OS Recovery

                                                                                  ----------------------------------------
